Page #184 background image
JOHNSON CONTROLS
184
FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
SECTION 7 – PARAMETER DESCRIPTIONS AND OPTIONS
MENU ITEM DEFINITION
COMP SYS A STATE
This parameter is programmed through the PROGRAM key and can be used to
manually establish the state of Compressor A system. It is also used to reset a
compressor that is locked out. The options are STOP, RUN and LOCKOUT.
COMP SYS A STATUS
This is the current operating mode of Compressor A The display shows Normal
- Inactive, Normal - Active, User Disabled, Warning, Safety Trip, Safety Fault,
Safety Lockout, Low Amb Inhibit.
COMP SYS B STATE
This parameter is programmed through the PROGRAM key and can be used to
manually establish the state of Compressor B system. It is also used to reset a
compressor that is locked out. The options are stop, run and lockout.
COMP SYS B STATUS
This is the current operating mode of Compressor B. The display shows Normal
- Inactive, Normal - Active, User Disabled, Warning, Safety Trip, Safety Fault,
Safety Lockout, Low Amb Inhibit.
COMP SYS C STATE
This parameter is programmed through the PROGRAM key and can be used to
manually establish the state of Compressor C system. It is also used to reset a
compressor that is locked out. The options are stop, run and lockout.
COMP SYS C STATUS
This is the current operating mode of Compressor C. The display shows Normal
- Inactive, Normal - Active, User Disabled, Warning, Safety Trip, Safety Fault,
Safety Lockout, Low Amb Inhibit.
COMP SYS D STATE
This parameter is programmed through the PROGRAM key and can be used to
manually establish the state of Compressor D system. It is also used to reset a
compressor that is locked out. The options are Stop, Run, Lock Out.
COMP SYS D STATUS
This is the current operating mode of Compressor D. The display shows Normal
- Inactive, Normal - Active, User Disabled, Warning, Safety Trip, Safety Fault,
Safety Lockout, Low Amb Inhibit.
COMP SYS E STATE
This parameter is programmed through the PROGRAM key and can be used to
manually establish the state of Compressor E system. It is also used to reset a
compressor that is locked out. The options are stop, run and lockout.
COMP SYS E STATUS
This is the current operating mode of Compressor E. The display shows Normal
- Inactive, Normal - Active, User Disabled, Warning, Safety Trip, Safety Fault,
Safety Lockout, Low Amb Inhibit.
COMP SYS F STATE
This parameter is programmed through the PROGRAM key and can be used to
manually establish the state of Compressor F system. It is also used to reset a
compressor that is locked out. The options are stop, run and lockout.
COMP SYS F STATUS
This is the current operating mode of Compressor F. The display shows Normal
- Inactive; Normal - Active, User Disabled, Warning, Safety Trip, Safety Fault,
Safety Lockout, Low Amb Inhibit.
COMPRESSOR A LOAD
This is the analog output in volts DC to the digital compressor controller for
Compressor A
COND BYPASS MAX POS
This parameter is programmed through the SETPOINTS key and establishes
the maximum allowable position for the condenser water bypass valve.
COND VALVE MIN POS
This parameter is programmed through the SETPOINTS key and establishes
the minimum allowable position for the condenser water valve.
COND VALVES INSTALLED
This parameter is programmed through the OPTIONS key and identies the
type of condenser water valve that is installed. The options are None, Cond
Only, Cond W/Bypass.
COND WATER CONTROL
This parameter is programmed through the PROGRAM key and can be used to
turn Condenser Water Control on or off. The options are User Enabled or User
Disabled.
COND WATER SYSTEM
This setting indicates what type of condenser water system the unit is connected
to. It is used to determine what position the water valves should be in when the
unit is on but not actively in the mechanical cooling mode.
TABLE 43 - DEFINITIONS (CONT'D)
