Chapter 2 OPERATIONS
2.7 SOFT KEY OPERATION
2-35
2
INSTRUCTION MANUAL
When the AIS destination ship is set, "$" is displayed in the AIS list.
"$" disappears when it is released.
Reference:
AIS data (Numerical Data) is displayed when the soft key 4 is set to "AIS Detail" in the
section "2.7.10 SETTING DISPLAY SCREEN"
Note:
Numerical Data, AIS retrieved vessel and AIS destination ship can be operated
when
Soft key 1: Numerical Data Retrieved Vessel DEST Ship
are selected.
Releasing AIS data display
1 Turn the [MULTI] control to select "AIS", then press the soft key 3
"Setting/Release".
Numerical Data, AIS retrieved vessel and AIS destination ship are canceled.
AIS Symbols
This section describes types and definitions of AIS symbols.
Symbol Definition Remarks
Activated AIS target This symbol shows the position of an AIS target on the PPI.
The shape is an isosceles triangle, and its vertex shows the
approximate heading direction.
If heading bearing information or COG information is not
received, the target is displayed toward PPI.
Selection When selecting an AIS target to display its numeric information,
this symbol is superimpose-displayed on the selected target.
This is displayed with a split square.
AIS SART This symbol shows the position of an AIS SART target on the
PPI.
This is displayed with a circle and cross lines.
To Next Page
