JRC JMA-3300 Series User Manual

Chapter 1

GENERAL AND EQUIPMENT COMPOSITION
1.3

CONFIGURATION
1-5
INSTRUCTION MANUA
L
1
PRODUCT NAME/MODEL QUANTITY JRC CODE REMARKS
Fuse
ST4-5AN1
4
Scanner NKE-2062/HS
For the scanner motor(F3)
JRC CODE: 5ZFCA00050
1 for installation
3 for spares
Fuse
ST4-6.3AN1
4
7ZXRD0013
Scanner NKE-2063$(DC12V)
For thecompoundmodulator(F2)
JRC CODE: 5ZFCA00051
1 for installation
3 for spares
Fuse
ST4-3.15AN1
4
Scanner1.(/$+6
$+6'&9 
For the compoundmodulator(F2) 
JRC CODE: 5ZFCA00047 
1 for installation
3 for spares
Fuse
ST4-5AN1
4
Scanner NKE-2063$+6$+6
For the scannermotor(F3)JRC
CODE: 5ZFCA00050
1 for installation
3 for spares
Carbon brush
54531-01
2
Scanner NKE-2063/$+6$+6
JRC CODE:BRXP05247
2for spares
Fuse
ST4-5AN1
4
7ZXRD0026
Scanner NKE-2103-4/4HS/6/6HS
For the modulator(F2)
JRC CODE: 5ZFCA00050
1 for installation
3 for spares
Fuse
ST6-10AN1
4
Scanner NKE-2103-4/4HS/6/6HS
For the power supply to motor(F3)
JRC CODE: 5ZFCA00053
1 for installation
3 for spares
