JRC JMA-3300 Series User Manual

Chapter 1

GENERAL AND EQUIPMENT COMPOSITION
1.3

CONFIGURATION
1-6
PRODUCT NAME/MODEL QUANTITY JRC CODE REMARKS
Connector
LTW-06BFFA-LL7001
1
7ZXRD0028
Display Unit NCD-2182
For GPS connection(J3)
JRC CODE: 5JCDX00032
1 for installation
Connector
LTW-07BFFA-LL7001
1
Display Unit NCD-2182
For NMEA connection(J4)
JRC CODE: 5JCDX00033
1 for installation
Connector
LTW-08BFFA-LL7001
1
Display Unit NCD-2182
For GPS compass connection(J5)
JRC CODE: 5JCDX00034
1 for installation
Option
PRODUCT NAME/MODEL QUANTITY JRC CODE REMARKS
Rectifier
NBA-5111
1 NBA-5111
For
NKE-2042
NKE-2043
NKE-2062/HS
NKE-2063$+6$+6
NKE-2103-4/4HS/6/6HS
Rectifier
NBD-865
1 NBD-865
For
NKE-2042
NKE-2043
NKE-2062
NKE-2063$
Equipment cable
H-CFQ-6912-5
H-CFQ6912-10
CFQ-6912-15
H-CFQ6912-20
H-CFQ6912-30
CFQ6912-5/10/15/20/30
Cable connecting the scanner unit
and the display unit
Length: 5/10/15/20/30 m
Cable with connectors at both
ends
Cable connecting a GPS compass
H-CFQ-6934
1 CFQ-6934 For JLR-10
Cable connecting a GPS compass
H-CFQ-5469
1 CFQ-5469 For JLR-20/30
Cable connecting NDW-51
H-CFQ-7082
1 CFQ-7082
Radar simulator
Cable connecting NDW-51
NSK unit
NCT-4106A
1 NCT-4106A
Gyro signal and
log signal acquisition
Sun Hood
MTV304869
1 MTV304869
