JRC JMA-3406 User Manual

PACKING LIST
xxiii
NKE-2043: SCANNER UNIT
Parts Name Figure Qty.
Packing List
[MTZ304378*]
1
Scanner Unit
[NKE-2043]
1
Mounting
Hardware
[MPXP34826*]
Bolt
[M8X30 SUS304]
4
Spring Washer
[SW8 SUS]
4
Washer
[W8 SUS]
4
Instruction for
Equipment
[MTZ304377*]
1
Template
[MTZ302447*]
1
Installation Cable (Option)
5, 10, 15, 20, 30m
[5m:H-CFQ-6912-5] / [10m:H-CFQ6912-10]
/ [15m:CFQ-6912-15] / [20m:H-CFQ6912-20]
/ [30m:H-CFQ6912-30]
1
Fuse [7ZXRD0012]
[ST4-6.3AN1]
Scanner NKE-2043(DC12V)
For the compound modulator(F2)
JRC CODE: 5ZFCA00051
1 for installation / 3 for spares
4
[ST4-3.15AN1]
Scanner NKE-2043(DC24V)
For the compound modulator(F2)
JRC CODE: 5ZFCA00047
1 for installation / 3 for spares
4
“ * ” means revision, such as A, B and so on.
