JRC JMA-3406 User Manual

PACKING LIST
xxiv
NKE-2063A/AHS: SCANNER UNIT
Parts Name Figure Qty.
Packing List
[MTZ305173*]
1
Scanner Unit
[NKE-2063A/AHS]
1
Mounting
Hardware
[MPXP35725*]
Brass Washer
[MTL325583]
4
Built-in Upset Bolt
[M6X12SUS+SW+W]
4
Instruction for
Equipment [MTZ305172*]
1
Installation Cable (Option)
5, 10, 15, 20, 30m
[5m:H-CFQ-6912-5] / [10m:H-CFQ6912-10]
/ [15m:CFQ-6912-15] / [20m:H-CFQ6912-20]
/ [30m:H-CFQ6912-30]
1
Earth Cable
[7ZCRD1501]
1
Fuse [7ZXRD0013]
[ST4-6.3AN1]
Scanner NKE-2062(DC12V)
For the modulator(F2)
JRC CODE: 5ZFCA00051
1 for installation / 3 for spares
4
[ST4-3.15AN1]
Scanner NKE-2062/HS(DC24V)
For the modulator(F2)
JRC CODE: 5ZFCA00047
1 for installation / 3 for spares
4
[ST4-5AN1]
Scanner NKE-2062/HS
For the scanner motor(F3)
JRC CODE: 5ZFCA00050
1 for installation / 3 for spares
4
Carbon Brush
[54531-01]
2
