JRC JMA-3406 User Manual

PACKING LIST
xxv
NKE-2103-4/4HS/6/6HS: SCANNER UNIT
Parts Name Figure Qty.
Packing List
[MTZ303832*]
1
Scanner Unit
[NKE-2103-4/4HS]
1
[NKE-2103-6/6HS]
Mounting
Hardware
[MPXP34097*]
Brass Washer
[MTL325583]
4
Built-in Upset Bolt
[M6X12SUS+SW+W]
4
Instruction for
Equipment
[MTZ303800*]
1
Name Plate
[MPNN45926*]
1
Installation Cable (Option)
5, 10, 15, 20, 30m
[5m:H-CFQ-6912-5] / [10m:H-CFQ6912-10]
/ [15m:CFQ-6912-15] / [20m:H-CFQ6912-20]
/ [30m:H-CFQ6912-30]
1
Earth Cable
[7ZCRD1501]
1
Fuse [7ZXRD0026]
[ST4-5AN1]
Scanner NKE-2103-4/4HS/6/6HS
For the modulator(F2)
JRC CODE: 5ZFCA00050
1 for installation / 3 for spares
4
[ST6-10AN1]
Scanner NKE-2103-4/4HS/6/6HS
For the power supply to
motor(F3)
JRC CODE: 5ZFCA00053
1 for installation / 3 for spares
4
“ * ” means revision, such as A, B and so on.

JRC JMA-3406 Specifications

General

Brand	JRC
Model	JMA-3406
Category	Marine Radar
Language	English
