Juniper EX2300 Series Hardware Guide

• Use the automacally created VLAN default for management—Select this opon to congure
all data interfaces as members of the default VLAN. Specify the management IP address and
the default gateway.
• Create a new VLAN for management—Select this opon to create a management VLAN.
Specify the VLAN name, VLAN ID, management IP address, and default gateway. Select the
ports that must be part of this VLAN.
• Congure out-of-band management —Congure the management port. In out-of-band
management, you use a dedicated management channel (MGMT port) to connect to the
management device. Specify the IP address and gateway of the management interface. Use this
IP address to connect to the switch.
7. Specify the SNMP read community, locaon, and contact to congure SNMP parameters. These
parameters are oponal.
8. Specify the system date and me. Select the me zone from the list. These opons are oponal.
9. The congured parameters are displayed. Enter yes to commit the conguraon. The conguraon
is commied as the acve conguraon for the switch.
10. (For EX4500 switches only) Enter the operaonal mode command request chassis pic-mode
intraconnect to set the PIC mode to intraconnect.
You can now log in with the CLI or the J-Web interface to connue conguring the switch. If you use the
J-Web interface to connue conguring the switch, the Web session is redirected to the new
management IP address. If the connecon cannot be made, the J-Web interface displays instrucons for
starng a J-Web session.
SEE ALSO
Connecng and Conguring an EX Series Switch (J-Web Procedure) | 175
Installing and Connecng an EX2200 Switch
Installing and Connecng an EX2300 Switch | 104
Installing and Connecng an EX3200 Switch
Installing and Connecng an EX3300 Switch
Installing and Connecng an EX3400 Switch
Installing and Connecng an EX4200 Switch
Installing and Connecng an EX4300 Switch
Installing and Connecng an EX4550 Switch
Installing and Connecng an EX4500 Switch
Installing and Connecng an EX6210 Switch
Installing and Connecng an EX8208 Switch
174

Juniper EX2300 Series Specifications

General

Software	Junos OS
Model	EX2300
Ports	24 or 48 10/100/1000BASE-T ports
Uplinks	4 x 1GbE/10GbE SFP+/SFP uplinks
Power Supply	Internal or external power supply options
Rack Units	1U
PoE/PoE+ Ports	Available on some models (EX2300-C and EX2300)
Operating Temperature	0° to 45°C
Input Voltage	100 to 240 VAC
Layer 3 Features	RIP, OSPF, VRRP
Layer 2 Features	VLAN, STP, RSTP, MSTP, LACP
Security Features	802.1X, DHCP snooping
Management	CLI, Web UI, SNMP
