Juniper EX2300 Series Hardware Guide

Table 42: Health Status (Connued)
Field Descripon
Temp. Indicates the chassis temperature status. Temperatures in the dashboard are listed in Celsius and
the corresponding Fahrenheit values.
NOTE: The Temp eld is unavailable for an EX4500 switch.
CPU load Indicates the average CPU usage over 15 minutes.
Fan status Indicates the status of the fans in the fan tray. The possible values are OK, Failed, and Absent.
This eld also indicates the direcon of airow of the fan tray. The possible values are Front to
back and Back to front.
EX4650 Switches
Fan status Indicates the status of the fans in the fan tray. The possible values are OK, Failed, and Absent.
NOTE: The fans are located on the side panel of the chassis.
Temp. Indicates temperature of the sensor near to Roung Engine.
Memory ul. Indicates the memory used in the Roung Engine.
CPU load Indicates the average CPU usage over 15 minutes.
EX6210 Switches
Memory ul. Indicates the memory used in the primary Roung Engine. Click the backup Roung Engine to
view the memory used in the backup Roung Engine.
CPU load Indicates the average CPU usage over 15 minutes.
Flash Indicates the usage and capacity of internal ash memory and any external USB ash drive.
Fan status Indicates the status of the fans in the fan tray. The possible values are OK, Failed, and Absent.
193

Juniper EX2300 Series Specifications

General

Software	Junos OS
Model	EX2300
Ports	24 or 48 10/100/1000BASE-T ports
Uplinks	4 x 1GbE/10GbE SFP+/SFP uplinks
Power Supply	Internal or external power supply options
Rack Units	1U
PoE/PoE+ Ports	Available on some models (EX2300-C and EX2300)
Operating Temperature	0° to 45°C
Input Voltage	100 to 240 VAC
Layer 3 Features	RIP, OSPF, VRRP
Layer 2 Features	VLAN, STP, RSTP, MSTP, LACP
Security Features	802.1X, DHCP snooping
Management	CLI, Web UI, SNMP
