Juniper EX2300 Series Hardware Guide

Table 49: Chassis Viewer for EX4550 Switches (Connued)
Field Descripon
Fan tray Mouse over the fan tray icon to display the status of the fans and airow direcon
informaon. For a Virtual Chassis, the status of the fans of the selected member switch is
displayed.
Virtual Chassis port Displayed only when switches are congured as a Virtual Chassis. In the image, the colors
listed below denote the Virtual Chassis port (VCP) status:
• Green—VCP is up and operaonal.
• Yellow—VCP is up but is nonoperaonal.
• Gray—VCP is down and nonoperaonal.
Power supplies Mouse over the power supply icons to display name, status, and descripon informaon.
PIC2 slot You can insert an uplink module or a Virtual Chassis module into the PIC2 slot. Mouse
over to display the details of the module inserted (uplink or Virtual Chassis).
Table 50: Chassis Viewer for EX4600 Switches
Field Descripon
Front View
NOTE: J-Web is supported on EX4600 switches only in J-Web Applicaon package Release 14.1X53-A2.
Interface status In the image, the colors listed below denote the interface status for both copper and ber
media type of ports:
• Green—Interface is up and operaonal.
• Yellow—Interface is up but is nonoperaonal.
• Gray—Interface is down and nonoperaonal.
Mouse over the interface (port) to view more informaon.
206

Juniper EX2300 Series Specifications

General

Software	Junos OS
Model	EX2300
Ports	24 or 48 10/100/1000BASE-T ports
Uplinks	4 x 1GbE/10GbE SFP+/SFP uplinks
Power Supply	Internal or external power supply options
Rack Units	1U
PoE/PoE+ Ports	Available on some models (EX2300-C and EX2300)
Operating Temperature	0° to 45°C
Input Voltage	100 to 240 VAC
Layer 3 Features	RIP, OSPF, VRRP
Layer 2 Features	VLAN, STP, RSTP, MSTP, LACP
Security Features	802.1X, DHCP snooping
Management	CLI, Web UI, SNMP
