Juniper EX2300 Series Hardware Guide

Table 54: Chassis Viewer for EX8216 Switches (Connued)
Field Descripon
LCD panel LCD panel congured for the LEDs on the ports. Mouse over the icon to view the current
character display.
Rear View
SF modules Mouse over the SF module icons in their respecve slots to display informaon. Slots are
numbered SF7–SF0, from le to right.
Table 55: Chassis Viewer for XRE200 External Roung Engines
Field Descripon
Front View
Interface status In the image, the colors listed below denote the interface status:
• Green—Interface is up and operaonal.
• Yellow—Interface is up but is nonoperaonal.
• Gray—Interface is down and nonoperaonal.
Mouse over the interface (port) to view more informaon.
For a Virtual Chassis conguraon, select the switch to view the interface status.
Console port The console port is used to connect the switch to a management console or to a
console server.
Management (me0)
port
The management port is used to connect the switch to a management device for out-
of-band management. Use this port for inial switch conguraon.
213

Juniper EX2300 Series Specifications

General

Software	Junos OS
Model	EX2300
Ports	24 or 48 10/100/1000BASE-T ports
Uplinks	4 x 1GbE/10GbE SFP+/SFP uplinks
Power Supply	Internal or external power supply options
Rack Units	1U
PoE/PoE+ Ports	Available on some models (EX2300-C and EX2300)
Operating Temperature	0° to 45°C
Input Voltage	100 to 240 VAC
Layer 3 Features	RIP, OSPF, VRRP
Layer 2 Features	VLAN, STP, RSTP, MSTP, LACP
Security Features	802.1X, DHCP snooping
Management	CLI, Web UI, SNMP
