Juniper EX2300 Series Hardware Guide

Table 4: Chassis Status LEDs in EX2300 Switches Except the EX2300-24MP and EX2300-48MP
Models
LED Label Color State and Descripon
SYS Green
• On steadily—Junos OS for EX Series switches
has been loaded on the switch.
• Blinking—The switch is boong.
• O—The switch is powered o or is halted.
ALM Red There is a major alarm.
NOTE: When you connect power to the switch, the
alarm LED (ALM) glows red. This behavior is
normal. Plugging an acve Ethernet cable into the
management port (MGMT) on the switch completes
the network link and turns o the ALM LED. (See
Connect a Device to a Network for Out-of-Band
Management .)
Connecng the switch to a dedicated management
console instead of a network does not aect the
ALM LED. The LED remains red unl the switch is
connected to a network.
Yellow There is a minor alarm.
NOTE: The ALM LED glows yellow if you commit a
conguraon to make it acve on the switch
without creang a rescue conguraon to back it
up. To save the most recently commied
conguraon as the rescue conguraon, enter the
operaonal mode command request system
configuration rescue save.
Unlit There is no alarm or the switch is halted.
27

Juniper EX2300 Series Specifications

General

Software	Junos OS
Model	EX2300
Ports	24 or 48 10/100/1000BASE-T ports
Uplinks	4 x 1GbE/10GbE SFP+/SFP uplinks
Power Supply	Internal or external power supply options
Rack Units	1U
PoE/PoE+ Ports	Available on some models (EX2300-C and EX2300)
Operating Temperature	0° to 45°C
Input Voltage	100 to 240 VAC
Layer 3 Features	RIP, OSPF, VRRP
Layer 2 Features	VLAN, STP, RSTP, MSTP, LACP
Security Features	802.1X, DHCP snooping
Management	CLI, Web UI, SNMP
