Table 21: Console Port Connector Pinouts for the QFX Series (Connued)
Pin Signal Descripon
5 Signal Ground Signal ground
6 RxD Input Receive data
7 DCD Input Data carrier detect
QSFP-DD Port Connector Pinout Informaon
Table 22 on page 57 provides the pinout mapping for Quad Small Form Factor Pluggable Double
Density (QSFP-DD) port connectors.
Table 22: QSFP-DD Network Port Pinout Mapping
Pin Symbol Descripon
1 GND Ground
2 TX2n Transmier inverted data input
3 TX2p Transmier non-inverted data input
4 GND Ground
5 TX4n Transmier inverted data input
6 TX4p Transmier non-inverted data input
7 GND Ground
