Table 22: QSFP-DD Network Port Pinout Mapping
(Connued)
Pin Symbol Descripon
53 RX7n Receiver inverted data output
54 GND Ground
55 RX5p Receiver non-inverted data output
56 RX5n Receiver inverted data output
57 GND Ground
58 GND Ground
59 RX6n Receiver inverted data output
60 RX6p Receiver non-inverted data output
61 GND Ground
62 RX8n Receiver inverted data output
63 RX8p Receiver non-inverted data output
64 GND Ground
65 NC No connect
66 TBD Reserved
67 VCC +3.3V power supply
