Docu-No.: 0590020601-EN Rev. 1.6.0 Page 17
Programming Reference 1
Calibration 1.2
AUTO FF CALIB
This action permits easy feeder calibration. For this the program
parameter <CAL DC> and <CAL TIME> have to be entered. Material
is discharged for the value of <CAL TIME> and the starting feeding
factor is calculated.
Notes:
• Calibration can be canceled with STOP.
•Pressing ENTER instead of RUN as noted above will abort the
AUTOFFCALIB routine and return the user to the HOME menu.
• Performing an AUTOFFCALIB function on an already running
feeder will have no effect upon operation.
▲ This command will start the feeder. Make sure that nobody is
working on the machine.
For KSU-II/KCM select this parameter, press ENTER twice
and then press RUN
For KSL press MORE-F5 then press then press RUN.
For KSC press then press RUN.
Attention
Refilling and feeding errors during calibration reset the program pa-
rameter FF INIT to <0> and activate the <FEEDFACTOR ERR>
alarm.
CAL PROD FED
Calibrate Product Fed
Shows the amount of material discharged during calibration cycle as
calculated by the controller.
Input range: Display only in set units
ACT PROD FED
Actual Product Fed
After the Feedfactor test has been completed, enter the weight of the
actual delivered product in this variable. The <SPAN> in the
CALIBRATION Menu will be automatically calculated.
If you wish to calculate the <SPAN> manually, just ignore this entry
and proceed to the SCALE Menu, GENERAL SCALE Sub-menu and
enter the computed span there.
Parameter
Definition
Table page 2 of 3
