2.4 Chassis
2.4.1 Weights
Maximum weights are shown. Actual weights of individual machines are dependent on equip‐
ment fitted (see machine nameplate).
Feature 01 02 03 04 05
Chassis type EU
chassis
EU
chassis
EU
chassis
US
chassis
Stationary
Height-adjustable towbar x x − − −
Fixed height towbar − − x x −
Parking brake − x x − −
Service brake − x − − −
Actual total weight [lb]*
Permissible axle load [lb] 1323 1323 1323 1323 −
x ≙ available, − ≙ not available
EU ≙ Europe, US ≙ United States of America
* Enter here the actual overall weight from the nameplate as reference,
Tab. 18 Machine weights
2.4.2 Tires
Characteristic/marking
Tire size 145/80 R 13
Maximum and recommended tire pressure [psig] 39
Wheel bolts M 12 x 1.5
Tab. 19 Tires
2.4.3 Wheel fixing tightening torque
Fixing medium Thread Wrench size Torque [lbf in]
Wheel bolt M 12 x 1.5 13/16” 800
Tab. 20 Wheel nut/bolt tightening torque
2.5 Compressor
2.5.1 Working pressure and FAD
Maximum working pressure [psig] 100
SIGMA airend 145
Free air delivery [cfm] 92
Tab. 21 Working pressure and FAD
2 Technical Data
2.4 Chassis
8
SERVICE MANUAL Screw Compressor
M26
No.: 9_9446 01 USE
