13 Annex

13.1 Marking

Fig. 51 Marking

1 VIN *) (stamped under the reflector)

*Vehicle identity number

2 Machine nameplate with serial number

3 Engine nameplate with serial number

4 Combined label for coupling loading and

built-in options

13.2 Pipeline and instrument flow diagram (P+I diagram)
