Item Sign Meaning
283* Battery contains acid.
Severe injury result from contact with battery acid.
➤
Do not allow battery acid to contact eyes, skin, clothing or painted surfa‐
ces..
➤ Do not attempt to jump-start if battery fluid is frozen.
➤ Bring temperature of battery up to at least 60°F before attempting to
jump-start it may explode.
303*
Fire or explosion caused by refueling.
Severe injury or death result from inflaming fuel.
➤
Use diesel fuel only.
➤ NEVER attempt to refuel the compressor while it is operating.
➤ Always replace fuel filter cap after refueling.
➤ Always wipe up fuel spills which may occur inside the compressor enclo‐
sure and allow the machine to ventilate.
310
311
Injury or damage from open machine.
➤
Operate the machine only when closed.
➤ Transport the machine only when closed.
320*
Loud noise and oil mist when the safety relief valve opens.
Ear damage and burns can result.
➤
Wear ear protection and protective cloths.
➤ Close all maintenance doors and cover panels.
➤ Work carefully.
330
331
332
Hot surface can cause burns.
➤
Let the machine cool down.
➤ Work carefully.
➤ Wear protective cloths and gloves.
390*
391*
Rotating fan blades and V-belt drive.
Injury and machine daSevere injury could result from touching the fan blades
and v-belt drive while it is rotating.mage possible.
➤
Never switch the machine on without guard in place over the fan blade.
➤ Isolate completely from the power supply (all conductors) and ensure the
supply cannot be switched on again (lock off).
420***
Injury or damage can result because tongue weight on this equipment may be
heavy.
➤
Do not lift drawbar by hand if weight is more than you can safely handle.
➤ See safety section of service manual.
* Location within the machine
** Only machines with generator
*** Only towable machines
