Protective functions
The ow control with valve control and ow monitor is adjusted with this function.
Pn.91: Flow control mode
Bit
-No.
Meaning Explanation
0
0: off (default)
Flow control mode
Flow control mode off/on
1: on
1
0: Operation (Default)
Mode drive active
2: bereits + ST
The function is active and the mode for the status "drive active" is selected. If the function is not active
(Pn.91 bit 0 = 0) no error and warning is triggered.
There are two adjustments for the status „drive active“:
operation The drive is active if the modulation is released.
ready + ST The drive is active, if all following conditions are met:
- the power unit is supplied (no NO_PU)
- there is no malfunction
- the control release is active (no NOP)
Pn.92: Valve control output selection
Name Function Decimal values
no no 0 (default)
O1 Transistor output 1
O2 Transistor output 2
R1 Relay output 4
R2 Relay output 8
OA Internal output 16
OB Internal output 32
OC Internal output 64
OD Internal output 128
