KEB COMBIVERT F5-A User Manual

Parameter
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 11.1 - 25
10
11
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
ru.79 abs. speed value (EMK) 024Fh RO np --- n * -4000 n * 4000 0
n *
0.125
rpm
5.1 - 4,7.1 - 3,7.1 - 14,7.4 - 1
4,7.6 - 4,7.8 - 7,7.13 - 10
ru.80 digital output state 0250h RO np --- 0 255 0 1 ---
7.1 - 3,7.1 - 14,7.3 - 15,7.3 -
16,7.3 - 25,10.1 - 11
ru.81 active power 0251h RO np --- -1000.00 1000.00 0.00 0.01 kW
7.1 - 3,7.1 - 14,7.2 - 11,7.2 -
13,7.3 - 20
ru.82 ramp. val. disp. high-res 0252h RO np --- -2^31 2^31-1 0 1 --- 7.1-3, 7.1-15, 7.4-7
ru.83 act. val. display high-res 0253h RO np --- -2^31 2^31-1 0 1 --- 7.1-3, 7.1-15
ru.84 accessible rel. position 0254h RO np --- -2^31 2^31-1 0 1 inc
7.1-3, 7.1-15, 7.12-65,
7.12-66, 7.12-74
ru.85 peak encoder 1 speed 0255h appl np --- 0 n * 4095.875 0
n *
0.125
rpm 5.1-4, 7.1-3, 7.1-15
ru.86 peak encoder 2 speed 0256h appl np --- 0 n * 4095.875 0
n *
0.125
rpm 5.1-4, 7.1-3, 7.1-15
ru.87 magnetizing current 0257h RO np --- -3276.7 3276.7 0 0.1 A
7.1 - 3,7.1 - 15,7.5 - 25,7.5 -
34,7.5 - 35
ru.89 actual source speed 0259h RO np --- n * -4000 n * 4000 0
n *
0.125
rpm 5.1-4, 7.1-3, 7.1-15
ru.90 max. torque in percent 025Ah RO np --- 0.00 400.00 0 0.01 %
7.1 - 3,7.1 - 15,7.2 - 11,7.2 -
13,7.8 - 3,7.8 - 14,7.8 - 15,7
.8 - 16
ru.91 energy over gtr 7 025Bh appl np --- 0 99999 0 1 KWh 7.1-15
ru.92 input power 025Ch RO np --- -1000.00 1000.00 0.00 0.01 kW 7.1-15
ru.93 power loss 025Dh RO np --- -1000.00 1000.00 0.00 0.01 kW 7.1-15
Sy.02 inverter identier 0002h cp-ro np --- identier identier identier 1 hex 7.1-4, 7.1-19
Sy.03 power unit code 0003h cp-ro np E 1 255 LTK 1 --- 7.1-4, 7.1-19, 8.1-7
Sy.04 cfg. data sel.data 0004h cp-ro np --- 0 24 0 1 --- 7.1-19
Sy.05 cfg. data 0005h RO np --- -32727 32767 0 1 --- 7.1-19
Sy.06 inverter address 0006h appl np E 0 239 1 1 --- 7.1-4, 7.1-19, 10.1-9
Sy.07 baud rate ext. bus 0007h appl np E 0 6 3 1 --- 7.1-4, 7.1-19, 10.1-9
Sy.08 bus synchronous time 0008h cp-ro np --- 0: off 65000 0: off 1 µs
7.1 - 4,7.1 - 20,7.12 - 77,7.1
2 - 80
Sy.09 HSP5 watchdog time 0009h cp-ro np E 0.00: off 10.00 0.00: off 0.01 s
7.1 - 4,7.1 - 20,7.3 - 21,7.12
- 80,7.13 - 7,10.1 - 10
Sy.10 F5-B; F5-G; F5-M 000Ah RO np --- 0 0 0 1 ---
Sy.11 baud rate int. bus 000Bh cp-ro np E 3 11 5 1 --- 7.1-4, 7.1-20, 10.1-9
Sy.12 message para. 1 den. 000Ch cp-ro np --- -1: off 7FFFH -1: off 1 hex
Sy.13 message parameter 1 set 000Dh cp-ro np --- 1 128 1 1 ---
Sy.14 message para. 2 den. 000Eh cp-ro np E -1: off 7FFFH -1: off 1 hex
Sy.15 message parameter 2 set 000Fh cp-ro np E 1 128 1 1 ---
Sy.16 proc. read data 1 den. 0010h appl np E -1: off 7FFFH -1: off 1 hex 7.12-78, 7.12-80
Sy.17 proc. read data 1 set 0011h appl np E 1 128 1 1 --- 7.12-80 , 7.16-12
Sy.18 proc. read data 2 den. 0012h appl np E -1: off 7FFFH -1: off 1 hex 7.12-78, 7.12-80
Sy.19 proc. read data 2 set 0013h appl np E 1 128 1 1 --- 7.12-80
Sy.20 proc. read data 3 den. 0014h appl np E -1: off 7FFFH -1: off 1 hex 7.12-80
Sy.21 proc. read data 3 set 0015h appl np E 1
128 1 1 --- 7.12-80
Sy.22 proc. read data 4 den. 0016h appl np E -1: off 7FFFH -1: off 1 hex
Sy.23 proc. read data 4 set 0017h appl np E 1 128 1 1 ---
Sy.24 proc. write data 1 def. 0018h appl np E -1: off 7FFFH -1: off 1 hex 7.12-80
Sy.25 proc. write data 1 set 0019h appl np E 1 255 255 1 --- 7.12-80
Sy.26 proc. write data 2 def. 001Ah appl np E -1: off 7FFFH -1: off 1 hex 7.12-80
Sy.27 proc. write data 2 set 001Bh appl np E 1 255 255 1 --- 7.12-80
Sy.28 proc. write data 3 def. 001Ch appl np E -1: off 7FFFH -1: off 1 hex 7.12-80
Sy.29 proc. write data 3 set 001Dh appl np E 1 255 255 1 --- 7.12-81
Sy.30 proc. write data 4 def. 001Eh appl np E -1: off 7FFFH -1: off 1 hex
Sy.31 proc. write data 4 set 001Fh appl np E 1 255 255 1 ---
Sy.32 scope timer 0020h RO np --- 0 65535 Sy.32 1 --- 7.1-4, 7.1-20
Sy.33
scope data 1 den. 0021h cp-ro np --- -1: off 7FFFH -1: off 1 hex
SY.34 scope data 1 set 0022h cp-ro np --- 1 128 1 1 --- 7.16-4
Sy.35 scope data 2 den. 0023h cp-ro np --- -1: off 7FFFH -1: off 1 hex
Sy.36 scope data 2 set 0024h cp-ro np --- 1 128 1 1 ---
Sy.37 scope data 3 den. 0025h cp-ro np --- -1: off 7FFFH -1: off 1 hex
Sy.38 scope data 3 set 0026h cp-ro np --- 1 128 1 1 ---
Sy.39 scope data 4 den. 0027h cp-ro np --- -1: off 7FFFH -1: off 1 hex
Sy.40 scope data 4 set 0028h cp-ro np --- 1 128 1 1 ---
SY.41 control word (high) 0029h appl np E 0 65535 0 1 hex 7.1-4, 7.1-21, 10.1-11
SY.42 status word (high) 002Ah RO np --- 0 65535 0 1 hex 7.1-4, 7.1-21, 10.1-13
further on next side
