KEB COMBIVERT F5-A User Manual

Page 11.1 - 26 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Parameter
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
SY.43 control word (long) 002Bh appl np E -2^31 2^311 0 1 hex
7.1 - 4,7.1 - 21,7.3 - 12,7.3 -
14,7.12 - 18,7.12 - 27,7.12
- 63,7.13 - 15,7.13 - 20,10.
1 - 11
SY.44 status word (long) 002Ch RO np --- -2^31 2^311 0 1 hex
7.1 - 4,7.1 - 21,7.13 - 16,7.1
3 - 18,10.1 - 13
Sy.45 drive mode reference value 002Dh appl np --- 0 n * 4095 n * 1500
n *
0.125
rpm 5.1-4
Sy.46 drive mode rotation 002Eh appl np --- 0 15 0 1 hex
SY.50 control word (low) 0032h appl np E 0 65535 0 1 hex
7.1 - 4,7.1 - 21,7.3 - 12,7.3 -
14,7.4 - 7,7.4 - 11,7.4 - 12,7
.12 - 18,7.12 - 19,7.12 - 27,
7.12 - 63,7.12 - 79,7.12 - 80
,7.13 - 14,7.13 - 15,7.13 - 1,
7.13 - 20,10.1 - 10,10.1 - 11
Sy. 51 status word (low) 0033h RO np --- 0 65535 0 1 hex
7.1-4, 7.1-20, 7.1-21,
7.3-19, 7.13-15, 7.13-17,
7.13-38, 10.1-12, 10.1-13
SY.52 set speed value 0034h appl np ---
-32000;
-64000;
-128000
32000; 64000;
128000
0 1; 2; 4 rpm
5.1-4, 7.1-4, 7.1-21, 7.4-4,
10.1-13
SY.53 actual speed value 0035h RO np ---
-32000;
-64000;
-128000
32000; 64000;
128000
0 1; 2; 4 rpm
5.1-4, 7.1-4, 7.1-21, 10.1-
13
Sy.54 message time stamps 0036h cp-ro np --- 0 255 0 1 hex
Sy.56 start display address 0038h cp-ro np E 0 7FFFH 0209h 1 hex 7.1-4, 7.1-22
Sy.57 watchdog time address 0039h cp-ro np --- -2 -1 -2 1 hex
Sy.58 proc. read data 5 den. 003Ah appl np E -1 7FFFH -1 1 hex
Sy.59 proc. read data 5 set 003Bh appl np E 1 128 1 1 ---
Sy.60 proc. read data 6 den. 003Ch appl np E -1 7FFFH -1 1 hex
Sy.61 proc. read data 6 set 003Dh appl np E 1 128 1 1 ---
Sy.62 proc. read data 7 den. 003Eh appl np E -1 7FFFH
-1 1 hex
SY.63 proc. read data 7 set 003Fh appl np E 1 128 1 1 ---
SY.64 proc. read data 8 den. 0040h appl np E -1 7FFFH -1 1 hex
Sy.65 proc. read data 8 set 0041h appl np E 1 128 1 1 ---
Sy.66 proc. write data 5 def. 0042h appl np E -1 7FFFH -1 1 hex
Sy.67 Proc. write data 5 set 0043h appl np E 1 255 255 1 ---
Sy.68 proc. write data 6 def. 0044h appl np E -1 7FFFH -1 1 hex
Sy.69 Proc. write data 6 set 0045h appl np E 1 255 255 1 ---
Sy.70 proc. write data 7 def. 0046h appl np E -1 7FFFH -1 1 hex
Sy.71 Proc. write data 7 set 0047h appl np E 1 255 255 1 ---
Sy.72 proc. write data 8 def. 0048h appl np E -1 7FFFH -1 1 hex
Sy.73 Proc. write data 8 set 0049h appl np E 1 255 255 1 ---
Sy.74 Proc. data 1-4 size 004Ah appl np E 0 65535 0 1
hex
Sy.75 Proc. data 5-8 size 004Bh appl np E 0 65535 0 1 hex
SY.77 Control word S4 004Dh appl np E 0 65535 0 1 hex
SY.78 Status word S4 004Eh appl np --- 0 65535 0 1 hex
SY.79 Status word 1 PROFIdrive 004Fh appl np --- 0 65535 0 1 hex 7.1-22
SY.80 Status word 2 PROFIdrive 0050h appl np --- 0 65535 0 1 hex 7.1-22
ud. 01 Password 0801h cp-ro np o.P. 0 9999 Application 1 --- 6.2-3, 7.16-12
ud.02 Control type 0802h appl np E 0 15 0 1 ---
5.1 - 5,6.2 - 9,7.1 - 5,7.2 - 10
,7.2 - 11,7.2 - 12,7.4 - 4,7.4 -
5,7.4 - 6,7.4 - 18,7.4 - 21,7.4
- 22,7.4 - 24,7.12 - 81,7.15 -
5,7.15 - 28
ud.02 Control type 0802h appl np E 0 15 8 1 ---
ud. 04 Auto store state 0804h appl np --- 0: off 1: on 1: on 1 ---
ud. 05 auto store 0805h appl np --- 0: off 2 1: on 1 --- 10.1-10
ud. 09 drive-mode-control 0809h appl np --- 0 11 0 1 ---
ud.15 CP selector 080Fh appl np E 1 36 1 1 ---
7.16 - 3,7.16 - 4,7.16 - 6,7.1
6 - 9
ud.16 cp address 0810h appl np E -1: off 7FFFH CP def. 1 hex
7.16 - 3,7.16 - 4,7.16 - 6,7.1
6 - 9
ud.17 cp set norm 0811h appl np E 1 8191 1 1 --- 7.16-3, 7.16-6
further on next side
