KEB COMBIVERT F5-A User Manual

Parameter
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 11.1 - 27
10
11
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
ud.18 divisor display norm 0812h appl P E -32767 32767 1 1 ---
7.16 - 5,7.16 - 6,7.16 - 7,7.1
6 - 8,7.16 - 9
ud.19 multiplier display norm 0813h appl P E -32767 32767 1 1 --- 7.16-7, 7.16-8, 7.16-9
ud.20 offset display norm 0814h appl P E -32767 32767 0 1 --- 7.16-7, 7.16-8, 7.16-9
ud.21 ctrl. display norm 0815h appl P E 0 1791 0 1 --- 7.16-6, 7.16-7, 7.16-8
ud. 22 PP selector 0816h appl np E 0 47 0 1 --- 7.16-12
ud.23 PP address 0817h appl np E -1: off 7FFFH -1: off 1 hex 7.16-12
ud.24 PP properties 0818h appl np E 1 2^20-1 1 1 --- 7.16-4, 7.16-12
ud. 25 PP write multiplier 0819h appl np --- -32767 32767 1 1 ---
ud. 26 PP write shifter 081Ah appl np --- 0 48 0 1 ---
ud. 27 PP read multiplier 081Bh appl np --- -32767 32767 1 1 ---
ud. 28 PP read shifter 081Ch appl np --- 0 48 0 1 ---
ud.29 PP offset 081Dh appl np --- -2^31+1 2^31-1 0 1 ---
ud.30 PP upper limit 081Eh appl np --- -2^31+1
2^31-1 1 1 ---
ud. 31 PP lower limit 081Fh appl np --- -2^31+1 2^31-1 0 1 ---
uf.00 Rated frequency 0500h appl P --- 0 n * 400 n * 50 ; 60
n *
0.0125
Hz
5.1-4, 6.2-4, 7.5-4, 7.5-6,
7.5-9
uf.01 Boost 0501h appl P --- 0.0 25.5 LTK 0.1 %
6.2-4, 7.5-4, 7.5-9,
7.15-22
uf.02 Additional frequency 0502h appl P ---
n * -0.0125:
parab.
n * 400 0: linear
n *
0.0125
Hz 5.1-4, 7.5-5, 7.5-9
uf.03 Additional voltage 0503h appl P --- 0.0 100.0 0.0 0.1 % 7.5-5, 7.5-9
uf.04 Delta boost 0504h appl P --- 0.0 25.5 0.0 0.1 % 7.5-4
uF.05 Delta boost time 0505h appl P --- 0.00 10.00 0.00 0.01 s 7.5-4
uf.06 energy saving mode 0506h appl P --- 0 79 0 1 ---
7.5-7, 7.5-11, 7.15-6
uf.06 energy saving mode 0506h appl P --- 0 127 0 1 ---
uf.07 energy saving factor 0507h appl P --- 0.0 130.0 70.0 0.1 % 7.5-7, 7.15-6
uF.08 energy saving input sel. 0508h appl np E 0
4095 0 1 ---
7.3 - 10,7.3 - 11,7.5 - 7,7.5 - 1
1,7.15 - 6
uf.09 Voltage stabilization 0509h appl np E 1 1120: off 1120: off 1 V
7.5 - 5,7.5 - 6,7.5 - 9,7.5 - 12
,7.5 - 13,7.6 - 5,7.13 - 33,7.
13 - 35
uF.10 Max. voltage mode 050Ah appl P --- 0 3 0 1 --- 7.5-4, 7.5-5
uF.11 Carrier frequency 050Bh appl P E 1 LTK LTK 1 ---
7.5-7, 7.10-5, 7.10-6
uF.11 Carrier frequency 050Bh appl P E 0 LTK LTK 1 ---
uF.12 base block time 050Ch RO np --- 0.05 10.00 LTK 0.01 s 7.13-16, 7.13-17
uF.13 base block voltage level 050Dh RO np --- 1 50 LTK 1 % 7.13-17
uF.14 Transistor on delay time 050Eh RO np --- 0 LTK LTK 0.05 µs
uF.15 hardw. curr. lim. mode 050Fh appl np E 0 2 1 1 ---
6.2 - 11,6.2 - 15,6.2 - 18,6.2
- 20,7.8 - 4,7.8 - 7,7.10 - 4,7
.13 - 5
uF.16 Autoboost conguration 0510h appl P --- 0 3 0 1 --- 7.5-9, 7.5-11
uF.17 Autoboost gain 0511h appl P --- 0.00 2.50 1.20 0.01 --- 7.5-9, 7.5-11
uF.18 deadtime comp. mode 0512h appl np E 0 3 0 1 ---
6.2 - 11,6.2 - 15,6.2 - 20,7.5
- 21,7.5 - 23,7.6 - 12,7.6 - 18
uF.21
Dead time compensation off
input selection
0515h appl np E 0 4095 0 1 ---
7.3-10, 7.3-12, 7.5-23, 7.6-
12
uF.22
Dead time e-compensation
limit
0516h sup np --- 0.00 10.00 0.00 0.01 µs
uF.23
Dead time e-compensation
factor
0517h sup np --- 0 32000 0 1 ---
uF.24 deadtime comp. PT1 time 0518h appl np --- 0.000 4095.938 0.000 0.063 ms
uF.25 dead time soft on/off 0519h appl np --- 0: off 1024 0: off 1.000 ms
