Page 7.1 - 14 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Operating and appliance data
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.71 Teach position 0247h RO - - -2147483647 2147483647 1 Inc -
This parameter displays the current teach position. This position remains until a new position is teached.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.73 Set torque in percent 0249h RO - - -400.0 400.0 0.1 % -
This parameter displays the adjusted set torque (ru.11) in percent at the input referring to the absolute tor-
que reference (cS.19).
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.74 act. torque in percent 024Ah RO - - -400.0 400.0 0.1 % -
This parameter displays the actual torque display (ru.12) at the input referring to the absolute torque refe-
rence in percent (cS.19).
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.78 Act. value display in
percent
024Eh RO - - -400.0 400.0 0.1 % -
This parameter displays the actual value (ru.07) in percent referring to the max. reference forward (oP.10).
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.79 Absolute speed value
(EMC)
024Fh RO - - -4000,000 4000,000 0.125 rpm -
In order to protect the inverter against overvoltage in the eld weakening range, an EMC dependent speed
should not be exceeded. This calculated value has priority to all other limits and it is displayed in ru.79.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.80 digital output state 0250h RO - - 0 255 1 - -
With do.51 digital output signals can be assigned to the hardware outputs (see chapter 7.3.). This parameter
displays the state of the output signals before the assignment in accordance with the following table. If seve-
ral outputs are set, the sum of the decimal values is indicated.
Bit
-No.
Dec.
value
Output Terminal
0 1 O1 (transistor output 1) X2A.18
1 2 O2 (transistor output 2) X2A.19
2 4 R1 (relay RLA,RLB,RLC) X2A.24...26
3 8 R2 (relay FLA,FLB,FLC) X2A.27...29
4 16 OA (internal output A) no
5 32 OB (internal output B) no
6 64 OC (internal output C) no
7 128 OD (internal output D) no
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.81 active power 0251h RO - - -400.00 400.00 0.01 kW -
The active power of the inverter is displayed with parameter ru.81. Negative values are displayed during
generatoric operation.
