Table of Contents
Table of Contents
2
Operations for Adjustment
5
Entering the Service Mode
5
Service Menu
6
Service Mode Functions
10
Disassembling and Assembling the Balance
12
Precautions
12
Removing the Case
13
Replacing Components
16
Replacing the Thermal Fuses (S18)
16
Replacing the Main Board Assembly (B2)
16
Replacing the Analog Board Assembly (B3)
17
Replacing the Power Board Assembly (B4)
19
Replacing the Inlet Assembly (S11)
20
Replacing the DBS Unit Assembly (U1)
21
Replacing the Detector Assembly (U11)
23
Replacing the Force Coil Assembly (L1)
24
Replacing the Sensor Shaft (U4)
27
Replacing the Glass Unit Assembly (S3)
27
Replacing the Windows Panel (C7)
27
Replacing the Top Case Grille (H2)
28
Replacing the DBS Heater (S5)
29
Replacing the Reflector Plate (H9)
29
Replacing the Fan Cable Assembly (C5)
30
Replacing the LSW Cable Assembly (C6)
31
Replacing the Right Hinge (H13), Left Hinge (H14), and Hinge Springs (H15)
32
Replacing the Thermistor (H10)
34
Replacing the Thermal Fuse (H6)
36
Replacing the Level Gauge Assy (B7)
37
Cheking the Eledctronic Board
38
Main Board Assembly (B2)
38
Analog Board Assembly (B3)
38
Power Board Assembly (B4)
39
Hardware Adjustment
41
Adjusting the Detector Assembly (U11) Height
42
Adjusting the Tilt Error
43
Adjusting the Cornerload Error
44
Software Adjustment
45
EPROM Initialization
45
Model Selection
45
How to Specify the Serial no Without Using a Computer
46
Factory Settings (Voltage/Usb)
47
Switching on and off the Setting Information Lock
47
Unlocking the Setting Information
47
Locking the Setting Information
47
Adjusting Linearity
48
Weight Value Input
48
Span Calibration
48
Temperature Calibration (Service Mode)
49
Temperature Calibration (User Mode)
49
Heater Operating Time Count
49
Eeprom
50
PRINT Operations
50
Data Edit (EDIT) Operations
51
Backup (BKUP) Operations
52
Download (RESTR) Operations
52
All Initialization (INIT) Operations
52
Performance Inspection
53
Repeatability
53
Cornerload Error
53
Instrument-To-Instrument Variability Inspection
53
Tilt Error
53
Temperature
54
Troubleshooting
55
General Corrective Measures
55
Error Display
58
Troubleshooting
59
Nothing Is Displayed
59
Reproducibility Pf Weight Measurements Is Poor
60
OL" or "-OL" Is Displayed
61
Lid Open/Close Status IS NOT Detected
63
Heater Does Not Come on
64
Does Not Reach Teperature Setting
65
ERR.124 Occurred
66
Parts
67
DBS Exploded View
67
DBS Maintenance Parts List
74
Tools
75
Optional Accessories List
75
