KERN DBS User Manual

10.3 Tools
No. Parts Name P/N
Remarks
J1 Leve
r
Positionin
g
Pin, fo
r
OPF 321-62674
J2 Shim for Setting Gap (t = 0.2 mm) 321-69034
J3 Handle for Cornerload Adjustment 321-69205
J4 Grind Stone 321-69206
J5 Check Wire Set 321-62356
J6 Flash Programmer, S-550SFW 321-71365
J7 Cable, S-550SFW 321-71371
J8 Unit Setting Jig Assy 321-72075-01
J9 Pan Support Jig 321-72076-01
J10 Plate, Temperature Calibration Kit 321-71521-01 Heat collector plate assembly
J11
Temperature Calibration Kit,
DBS
321-71520-21
JCSS measurement points: 1 point (160 °C), certificate (including
English)
J12 Cap nut,M3 023-33130 (*5) Parts for Plate,thermal cal kit
J13 Jig cable,2P 321-72077-01
J14 Jig cable,7P-7P 321-72078-01
Torque Driver, 6LTDK 321-72079-01
Torque Driver, 30LTDK 321-72079-02
Torque Driver, 50LTDK 321-72079-03
Hex Bit SB2.5 (for M3) 321-72080-01
Hex Bit SB3 (for M4) 321-72080-02
Nut Driver #5 (for #4-40UNC) 086-12003 (*5)
Nut Driver #7 (for M4) 086-12005 (*5)
Wrench 5.5×7 (for M3/M4)
086-03050 (*5)
Ball Driver, BS2.5 (for M3 sockets) 086-12023 (*5)
Ball Driver, BS3 (for M4 sockets) 086-12024 (*5)
Soldering Iron, FX-951-01 (for
Pb-free)
086-72039-01 (*5)
Solder, P3M705-0, 8 (Pb-free) 018-52130-03 (*5)
Tester (+/- 5.00 V) (*5)
10.4 Optional accessories list
No. Parts Name P/N
Remarks
P
r
otective Cove
r
321-71512-10
Setof5
Aluminum Sheets 321-71571-10 1 box (50 sheets)
Fiberglass Sheets 321-71371 1 box (100 sheets)
Temperature Calibration Kit,
DBS-A01
321-71520-54
Sample Pan (stainless steel) 321-71572-10 Set of 5
RS-232C Cable 321-61967
USB cable 088-52848-32
Tongs 321-71623
(*1) Indicated in User's Manual. User replaceable maintenance parts.
(*3) Use PTFE tube(inside diameter 1.5mm, outside diameter 2.5mm)(016-37514-20) for inside hook
end protection of spring hinge
(*5) No stock in our factory. Please prepare items refer to specification on the drawing by yourself.
DBS-SH-e-1210 75
