cing the The
r
mist
o
r
(
H10)
1) Remove the hinges by following the procedure in 2.3.17 Replacing the Right Hinge (H13), Left Hinge
(H14), and Hinge Springs (H15).
Loosen the two self-tapping flat head screws (H59) and two P4 M4
× 8 screws (H58) and remove the
blind cover (H11) (Fig. 50).
Pull the thermistor (H10) (gray line) out from the hole in the side wall of the top case (H1) (Fig. 51).
2)
3)
H11 H10
H
5
8
H
5
8
H1
H
5
9
H
5
9
Fig. 50
Fig. 51
