KERN DBS User Manual

10.2 DBS Maintenance Parts List
No. Parts Name P/N
Remarks
2 Sheet Panel, DBS 321-72203
8 Packing box assy, DBS 321-71514-11 Including cushioning material
P1 Packing box, DBS 321-72207 Outer box only
S2 Case Assy, DBS Service 321-71738-11 including sheet panel, window panel, etc.
S3 Glass Unit Assy 321-72172-01
S4 Spring, Grounding 321-71601
S5 Heater, 240 V 321-71534-02 (*1) Includes hex wrench
S6 Window, Display 321-71037 LCD window
S11 Pan Supporter Assy 321-71598 (*1)
S12 Windbreak 321-71720 (*1)
S13 Heater Insulation Plate 321-71736-02 (*1) Including caution label
S17 Power Cord, 240 V 071-60825-51 (*1) For regions with 220 to 240 V (Germany, etc.)
S18 Fuse, 240 V 072-02004-21 (*1) Rated 250 V / 3.15 A
G2 Cushion, Rubber 321-71573 (*1)
G4 Glass.Main 321-71450-01 (*1)
G5 Glass,Front 321-71451-01 (*1)
B2 Main Board Assy 321-71373-41
B3 Analog Board Assy, CE600 321-64556-14
B4 Power Board Assy, with USB 321-71746-41 Including 2 D-sub screws
B6 Level Adjuster Assy 321-64540
B7 Level Gauge Assy 321-70691-01
B8 Cable, ILS 9P 321-64566-01
B9 Cable, ILS MOC 11S 321-71383-41
B10 Cable, ILS MOC 10S 321-71383-41
B11 Inlet Assy,service 240V 321-71745-02 220-240V power supply inlet
B23 Unit cover,lower 321-71511
C1 Heater Case Assy 321-71507-01
C3 Top Base Assy,service 321-71742-11 Including caution label
C5 Fan Cable Ass
y
.service 321-71740-41 Including cushion tape
C6 LSW Cable Assy 321-71384-41
C7 Window Panel Assy,service 321-71743-01 Sample Observation Window Including caution label
H1 Top Case Assy,service 321-71741-01 Including aluminum tape
H2 Top Case, Grill,service 321-71744-01 Including caution label
H6 Thermal Fuse, DM150V 072-01843-19
H7 Heater Junction Cable 321-71380-41
H8 FG Ground Cable 321-71381-41
H9 Reflector Plate, T0.3 MIRO 321-71586-01
H10 Thermistor, E1M-312-S11 321-71336
H12 Saddle, Wire WS-A-1-19 072-60611-01
H13 Right Hinge, for Top Case 321-71433 LSW side
H14 Left Hinge, for Top Case 321-71501
H15 Spring, Hinge D1.6 321-71602-04 (*3)
H24 Rubber sponge 321-72146
U1 Aging Unit Assy, MOC-T 321-71525-01
U4 Sensor Shaft 321-71436
U9 Magnet Assy 321-55222-12
U11 Assy, Detector 321-64559
U17 Pt-Ni Band, 1M 321-70188-01 014-54301 1 m reel
U19 Cable, ILS 7S-7S-140 321-64566-04
U20 Cable, ILS 2S-90 321-64567-01
L1 Force Coil Assy 321-53912-10
T3
Packing Carton Assy, Temperature
Calib
r
ation DBS
321-72242-54
O1 Plate,thrmal cal kit 321-71521-01 Heat consentration plate
O2 Cap nut,M3 023-33130 (*5) Parts for Plate,thermal cal kit
74 DBS-SH-e-1210
