144 Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide

10 Triggers

Serial Trigger

With serial decode option licenses (see “Serial Decode Options" on page 107),

you can enable serial trigger types. To set up these triggers, see:

• “CAN Triggering" on page 303

• “I2C Triggering" on page 318

• “LIN Triggering" on page 311

Table 3 Half-field holdoff time

Standard Time

NTSC 8.35 ms

PAL 10 ms

PAL-M 10 ms

SECAM 10 ms

Figure 20 Using Field Holdoff to Synchronize to Color Field 1 or 3 (Field 1 mode)
