Keysight Technologies MSO-X 2002A User Manual

113
Keysight InfiniiVision 2000 X-Series Oscilloscopes
User's Guide
8 Display Settings
To adjust waveform intensity / 113
To set or clear persistence / 115
To clear the display / 116
To select the grid type / 116
To adjust the grid intensity / 117
To freeze the display / 117
To adjust waveform intensity
You can adjust the intensity of displayed waveforms to account for various signal
characteristics, such as fast time/div settings and low trigger rates.
Increasing the intensity lets you see the maximum amount of noise and
infrequently occurring events.
Reducing the intensity can expose more detail in complex signals as shown in the
following figures.
1 Press the [Intensity] key to illuminate it.
This key is located just below the Entry knob.
2 Turn the Entry knob to adjust the waveform instensity.
Waveform intensity adjustment affects analog channel waveforms only (not math
waveforms, referencewaveforms, digital waveforms, etc.).

Keysight Technologies MSO-X 2002A Specifications

General

Form Factor	Benchtop
Vertical Resolution	8 bits
Display Size	8.5 inches
Waveform Update Rate	50, 000 waveforms/sec
Sample Rate	2 GSa/s
Memory Depth	1 Mpts
Display	8.5 inch
Display Type	WVGA LCD
Waveform Capture Rate	50, 000 waveforms per second
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse Width, Pattern, Serial
Operating Temperature	0°C to +50°C
Weight	5.5 kg

Summary

1 Getting Started

Connect Probes to the Oscilloscope

Guides on connecting probes to the oscilloscope channel BNC connectors.

2 Horizontal Controls

To adjust the horizontal (time/div) scale

Adjusts the time per division setting using the horizontal scale knob.

To adjust the horizontal delay (position)

Controls horizontal positioning of the trigger point relative to the time reference.

3 Vertical Controls

To adjust the vertical scale

Sets the vertical sensitivity (volts/division) for each analog channel.

To adjust the vertical position

Moves the waveform up or down on the display for better viewing.

4 Math Waveforms

To perform a transform function on an arithmetic operation

Performs operations like add, subtract, multiply, and FFT on analog signals.

6 Digital Channels

To connect the digital probes to the device under test

Guides on connecting digital probes for mixed-signal oscilloscope use.

7 Serial Decode

10 Triggers

Adjusting the Trigger Level

Sets the vertical level for analog channel edge detection.

Pattern Trigger

Triggers based on a specific logic pattern across multiple channels.

11 Trigger Mode/Coupling

12 Acquisition Control

Running, Stopping, and Making Single Acquisitions (Run Control)

Manages the oscilloscope's acquisition process using Run/Stop and Single keys.

Selecting the Acquisition Mode

Chooses acquisition modes like Normal, Peak Detect, Averaging, High Resolution.

13 Cursors

To make cursor measurements

Uses horizontal and vertical markers for custom measurements.

14 Measurements

To make automatic measurements

Configures and displays automatic measurements on waveforms.

15 Mask Testing

To create a mask from a "golden" waveform (Automask)

Automatically generates a mask from a reference waveform.

17 Waveform Generator

18 Save/Recall (Setups, Screens, Data)

21 Web Interface

23 CAN/LIN Triggering and Serial Decode

Setup for CAN Signals

Connects to CAN signals and specifies parameters for capture.

CAN Triggering

Configures triggers for CAN messages based on frame ID, data, or errors.

CAN Serial Decode

Decodes captured CAN data and displays it in a readable format.

24 I2C/SPI Triggering and Serial Decode

Setup for I2C Signals

Connects to I2C signals and sets threshold voltage levels.

I2C Triggering

I2C Serial Decode

25 UART/RS232 Triggering and Serial Decode

Setup for UART/RS232 Signals

UART/RS232 Triggering

UART/RS232 Serial Decode
