Measurements 14

Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide 185

Snapshot All

The Snapshot All measurement type displays a popup containing a snapshot of all

the single waveform measurements.

“Rise Time" on page 195

“DC RMS" on page 190

“AC RMS" on page 191

“Top" on page 187

“+ Width" on page 195 Yes

“– Width" on page 195 Yes

Use the cursors to make other measurements on FFT.

Measurement Valid

for

Math

FFT

Valid for

Digital

Channels

Notes
