226 Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide

17 Waveform Generator

To set up Frequency-Shift Keying Modulation (FSK)

In the Waveform Generator Modulation Menu (under [Wave Gen] > Settings >

Modulation):

1 Press the Type softkey and turn the Entry knob to select Frequency-Shift Keying

Modulation (FSK).

2 Press the Hop Freq softkey and turn the Entry knob to specify the "hop

frequency".

The output frequency "shifts" between the original carrier frequency and this

"hop frequency".

3 Press the FSK Rate softkey and turn the Entry knob to specify the rate at which

the output frequency "shifts".

The FSK rate specifies a digital square wave modulating signal.

The following screen shows an FSK modulation of a 100 kHz sine wave carrier

signal.
