242 Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide
19 Print (Screens)
4 Press the Options softkey to select the print options.
See “To specify the print options" on page 244.
5 Press the Palette softkey to select the print palette. See “To specify the palette
option" on page 244.
6 Press the Press to Print softkey.
You can stop printing by pressing the Cancel Print softkey.
You can also configure the [Quick Action] key to print the display. See “Configuring
the [Quick Action] Key" on page 262.
See Also • “Adding an Annotation" on page 263
To set up network printer connections
When the DSOXLAN LAN/VGA module is installed, you can set up network printer
connections.
A network printer is a printer attached to a computer or print server on the
network.
1 Press the [Print] key on the front panel.
The oscilloscope will print the last menu visited before you pressed the [Print] key. Therefore,
if you have measurements (Amplitude, Frequency, etc.) showing on the display before you
press [Print], the measurements will be shown on the printout.
To print the display showing the Print Configuration Menu at the bottom, press the [Print] key
twice; then, press the Press to Print softkey.
