184 Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide
14 Measurements
Measurements Summary
The automatic measurements provided by the oscilloscope are listed in the
following table. All measurements are available for analog channel waveforms. All
measurements except Counter are available for math waveforms other than FFT. A
limited set of measurements is available for math FFT waveforms and for digital
channel waveforms (as described in the following table).
Measurement Valid
for
Math
FFT
*
Valid for
Digital
Channels
Notes
“Snapshot All" on page 185
“Amplitude" on page 187
“Average" on page 190 Yes, Full
Screen
“Base" on page 188
“Delay" on page 196 Measures between two sources.
Press Settings to specify the second
source.
“Duty Cycle" on page 195 Yes
“Fall Time" on page 195
“Frequency" on page 194 Yes
“Maximum" on page 187 Yes
“Minimum" on page 187 Yes
“Overshoot" on page 188
“Peak-Peak" on page 186 Yes
“Period" on page 193 Yes
“Phase" on page 197 Measures between two sources.
Press Settings to specify the second
source.
“Preshoot" on page 189
