Getting Started 1
Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide 41
Front Panel Overlays for Different Languages
Front panel overlays, which have translations for the English front panel keys and
label text, are available in 10 languages. The appropriate overlay is included when
the localization option is chosen at time of purchase.
To install a front panel overlay:
1 Gently pull on the front panel knobs to remove them.
2 Insert the overlay's side tabs into the slots on the front panel.
19. USB Host port This port is for connecting USB mass storage devices or printers to the
oscilloscope.
Connect a USB compliant mass storage device (flash drive, disk drive, etc.)
to save or recall oscilloscope setup files and reference waveforms or to
save data and screen images. See Chapter 18, “Save/Recall (Setups,
Screens, Data),” starting on page 229.
To print, connect a USB compliant printer. For more information about
printing see Chapter 19, “Print (Screens),” starting on page 241.
You can also use the USB port to update the oscilloscope's system
software when updates are available.
You do not need to take special precautions before removing the USB mass
storage device from the oscilloscope (you do not need to "eject" it). Simply
unplug the USB mass storage device from the oscilloscope when the file
operation is complete.
CAUTION: Do not connect a host computer to the oscilloscope's USB
host port. Use the device port. A host computer sees the oscilloscope as a
device, so connect the host computer to the oscilloscope's device port (on
the rear panel). See “I/O Interface Settings" on page 247.
There is a second USB host port on the back panel.
20. Digital channel
inputs
Connect the digital probe cable to this connector (MSO models only). See
Chapter 6, “Digital Channels,” starting on page 89.
21. Waveform
generator
output
Outputs sine, square, ramp, pulse, DC, or noise on the Gen Out BNC. Press
the [Wave Gen] key to set up the waveform generator. See Chapter 17,
“Waveform Generator,” starting on page 217.
