Keysight InfiniiVision 2000 X-Series Oscilloscopes
User's Guide
14 Measurements
To make automatic measurements / 182
Measurements Summary / 184
Voltage Measurements / 186
Time Measurements / 193
Measurement Thresholds / 198
Measurement Window with Zoom Display / 200
The [Meas] key lets you make automatic measurements on waveforms. Some
measurements can only be made on analog input channels.
The results of the last four selected measurements are displayed in the
Measurements information area on the right-hand side of the screen.
Cursors are turned on to show the portion of the waveform being measured for the
most recently selected measurement (bottom-most on the right-side
measurement are).
Post Acquisition Processing
In addition to changing display parameters after the acquisition, you can perform all of the
measurements and math functions after the acquisition. Measurements and math functions
will be recalculated as you pan and zoom and turn channels on and off. As you zoom in and out
on a signal using the horizontal scale knob and vertical volts/division knob, you affect the
resolution of the display. Because measurements and math functions are performed on
displayed data, you affect the resolution of functions and measurements.
