264 Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide
20 Utility Settings
3 In the Annotation Menu, press Annotation to enable the annotation.
4 Press Edit.
5 In the Edit Annotation Menu:
• Use the Spell, , , and Delete Character softkeys to enter the annotation
text:
• Spell — press this softkey and turn the Entry knob to select the character
at the current position.
• — press this softkey to enter characters and move the cursor to the
next character position.
• — press this softkey to enter characters and move the cursor to the
previous character position.
• Delete Character — press the or softkeys until the desired character
is highlighted; then, press this softkey to delete the character.
You can use a connected USB keyboard instead of using the Spell (and other) character
editing softkeys.
