Getting Started 1

Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide 37

10. [Auto Scale]

key

When you press the [AutoScale] key, the oscilloscope will quickly

determine which channels have activity, and it will turn these channels on

and scale them to display the input signals. See “Use Auto Scale" on

page 30.
