DNS Hostname
A hostname is the host portion of the domain name, which is translated into an IP address.
Each power supply is shipped with a default hostname with the format: Keysight-modelnumber-serialnumber,
where modelnumber is the power supply’s 6-character model number (e.g. E36231A), and serialnumber is the last
five characters of the 10-character power supply serial number located on the label on the top of the unit (e.g.
45678 if the serial number is MY12345678).
– The instrument receives a unique hostname at the factory, but you may change it. The hostname must be unique
on the LAN.
– The name must start with letter; other characters can be an upper- or lower-case letters, numeric digits, or
dashes ("-").
– This setting is non-volatile; it will not be changed by power cycling or *RST or SYSTem:PRESet.
1. Press Utilities > I/O Config > LAN Settings.
2.
Select DNS Hostname field using the navigation keys. Press and enter the hostname with the keyboard
provided. Press Back.
3. Press Yes to save the setting.
4. Press No to cancel all the changes and exit without saving.
52
