Keysight E36200 Series User Manual

Step 4 – Turn on Output 1, start the sequencing and log the data
Press Back to return the display to the data logger view.
– Press Output 1 [On] to turn on Output 1.
– Press Run Stopped to run the data logger. The data logger will be initiated and Output 1 trace is displayed on the
screen.
– Press Output LIST > Run Stopped to start output sequencing.
The data logger will run for 30 seconds and log the voltage data from output 1. When the data log completes, you
should see the output waveform displayed as follows:
A message will indicate that the logged data has been saved in a file named default.dlog. If you wish to save the data
under a different filename, you must specify the filename before the data logger runs.
Press File Name located at the data logger Properties menu to specify a filename.
Step 5 – Export the data
After you have completed the data logging, you can use the Export File key to export the logged data to a .csv
(comma separated values) file.
96
Keysight E36200 Series User's Guide
