Keysight E36200 Series User Manual

Using the Output LIST
The Output LIST allows single or multiple outputs to run in sequence. You can set the followings for each of the
output in sequence.
1.
Set the step that will generate the trigger out signal at the beginning/end of the step.
2.
Set the last output value after the sequence list completes.
3.
Set how the list responds to triggers.
4.
Set the transient mode for voltage and current.
5.
Set the trigger source for the transient system.
6.
Set the trigger delay in seconds.
7.
Set the list repeat count.
8.
Set the list to repeat continuously.
You can configure up to 100 voltage and current steps in the Output LIST window.
Step 1– Add/remove steps to/from the LIST
Press Output LIST to access the Output LIST window.
Press Add to insert a new step below the selected step. Note that the values in the new step are copied from the
previous step. Continue to add steps until your sequence is complete. Use the navigation keys to move through the
list.
Press Delete if you want to delete the selected step or press Clear All if you want to remove all steps from the list.
Keysight E36200 Series User's Guide 89
