Keysight E36200 Series User Manual

Step 2 – Configure the output sequence
Configure the Voltage, Current, Time, BOST, and EOST accordingly. Use the navigation keys to select the field; use
the numeric entry keys to enter the value. The value is set when you press [Enter].
Fields Description
Voltage Sets the voltage value for selected step in voltage.
Current Sets the current value for selected step in ampere.
Time Sets the run-time for selected step in seconds.
BOST Enables check box to set which step will generate a trigger-out signal at the beginning of the step (BOST).
EOST Enables check box to set which step will generate a trigger-out signal at the end of the step (EOST).
For additional settings, press Properties to open the Output LIST Properties window. Configure the Output LIST
accordingly. Refer to the below table for details.
90
Keysight E36200 Series User's Guide
