Keysight E4990A - Page 16

E4990A Help
6
Hard keys
Hard Keys (Keys located on the
Front panel of E4990A) are
displayed in Blue color, Bold in
Verdana with 12 pt size.
Trace Max
Foc
Marker
Softkeys
Also known as menu keys, are
the names of menu that appear
in the Firmware (Software) of
E4990A and are displayed as
Bold in Arial with 12 pt size.
Auto Scale All
Allocate Channels
BLOCK
Names
E4990A Front Panel is divided
into 7 blocks. These blocks are
displayed in ALL CAPS, Green
Color, Bold in Arial with 12 pt
size, followed by the word
'Block'.
RESPONSE Block
ENTRY Block
STIMULUS Block
Note
This Note sign denotes
important information. It calls
attention to a condition that is
essential for the user to
understand.
Thi
s is a
Note.
Caution
This Caution sign denotes a
hazard. It calls attention to a
procedure, practice, or
condition that, if not correctly
performed or adhered to, could
result in damage to or
destruction of part or all of the
instrument.
Thi
s is a
Caution.
Warning
This warning sign denotes a
hazard. It calls attention to a
procedure, practice, or
condition that, if not correctly
performed or adhered to, could
result in injury or death to
personnel.
Thi
s is a
Warning
.
