E4990A Help
188
1. Press File Dialog... to open the Open dialog box.
2. Select the folder and the file using the external keyboard and mouse.
3. Click Open.
The warning messages may appear when recall fails:
Pressing Save/Recall > Explorer executes Windows
Explorer. This helps you to browse the files in the SSD of the
E4990A.
Recall Procedure using " Recall by File Name"
You can use the recall feature with the Recall by File Name softkey for files
you have named freely and save in the D:\State folder. This function lets
you recall a file you have named freely and save by simple softkey
operation, eliminating annoying operation using the Open dialog box.
Although there is no limit to the number of files
saved in a folder, only up to 50 files are displayed on the
softkeys. If more than 50 files are saved in a folder, they are
sorted in the order of numbers 0 to 9 and alphabetic characters
A to Z and the first 50 files are displayed as softkeys.
Although there is no limit to the number of characters of a file
name, only up to 16 characters are displayed on the softkey. If
a file name exceeds 16 characters, the first 12 characters are
displayed on the softkey and the remaining characters are
omitted and replaced with "...".
Different files may be displayed on softkeys with the
same name or a saved file is not displayed on any softkey
because of the above limitations.
1. Press Save/Recall > Recall by File Name.
2. Files that have been named and saved in the D:\State folder are
displayed on softkeys. Press the key for the file you want to recall.
Priority of Recalling Configuration File at Startup
If several instrument configuration files exist at the startup of the E4990A,
only one file is recalled and set at a time in the following order of priority.
If these files do not exist, the normal preset (factory preset) is executed.
Priority Recalled file
1
Configuration file for the auto-recall function in the A drive
(If external floppy disk drive is connected.)
To Next Page
