Measurement
195
Other topics about Data Output
Overview
By connecting a printer to the USB port of the E4990A, you can print the
displayed screen of the E4990A.
Printed/Saved Images
The display image saved in the volatile memory (clipboard) is
printed/saved. If no image is saved in the clipboard, the image displayed
at the time of print execution is printed/saved.
Saving image to clipboard
The System key also has a screen capture feature. When you press System
key, the image displayed on the screen immediately before pressing is
saved in the clipboard.
The image in the clipboard is cleared when you execute
print/save.
Print Procedure
Preparation before printing
Follow these steps to prepare for printing:
1. Turn ON the printer and connect it to E4990A.
2. Turn ON the E4990A.
3. Press System key.
4. Press Printer Setup. The Printers window opens. The icons of the
printers that have been connected are displayed in the window. When
you connect a print for the first time, it is automatically registered and
its icon is added in the window.
5. The printer with the check mark ( ) on its icon is selected as the
default printer for printing. If you want to change it, select (highlight)
the icon of your preferred printer in the Printers window and then click
Set as Default Printer in the File menu.
6. Right click the printer that selected for printing and then click Printing
Preferences in the menu. The Printing Preferences dialog box for the
selected printer appears. Set items necessary before printing such as
Page Size and then click the OK button.
7. Click Close in the File menu.
Executing print
Follow these steps to print the screen information:
1. Display the screen you want to print.
2. Press System key to save the currently displayed screen onto the
clipboard.
