Instr Setup
Displays the short-cut keys to make quick setup.
Macro Setup
Displays the Macro Setup Menu in Softkey Menu Bar.
Macro Menu
Displays macro list to be executed which is registered
in the macro setup.
Save/Recall
Displays the Save/Recall Menu in Softkey Menu Bar.
Manipulating the Save/Recall Menu enables you to
store the setup conditions to or read from the storage
devices, calibration data, and trace data of the
analyzer.
Capture/System
First, temporarily saves the data for the image
displayed on the LCD screen the moment this key is
pressed to the internal memory (clipboard).
Immediately after that, displays the System Menu in
Softkey Menu Bar. Manipulating the System Menu
enables you to define the setup for the limit test and
then execute it, or to define the setup for the control
and management of the analyzer. Using the Dump
Screen Image option enables you to store the image
data in the clipboard to a file on the storage devices.
Also, using the Print option in the System menu
enables you to print the image data in the clipboard
to a printer.
Preset
One message will prompt on the screen display and
click OK in the message to return the analyzer to the
initial setup state, called as factory state.
MKR/ANALYSIS Block
A group of keys used for analyzing the measurement results by using the
markers and etc.
Hardkey
Name
Description
Marker
Displays the Marker Menu in Softkey Menu Bar.
Manipulating the Marker Menu enables you to turn the
markers on/off and move them by entering stimulus
values. You can place up to 10 markers on each trace.
