SCPI.SERVICE.CHANNEL(Ch).CAL(Type).SHORT
:SERV:CHAN:DISP:ANN:XAX:MODE:BIAS
Type
Command/Query
Syntax
:SERVice:CHANnel<Ch>:DISPlay:ANNotation:XAXis:MODE:BIAS
{SSTop|CSPan}
:SERVice:CHANnel<Ch>:DISPlay:ANNotation:XAXis:MODE:BIAS?
Description
This command sets/gets x-axis annotation mode (Start/Stop or
Center/Span).
Variable
Parameter Selection Option
Description X-axis annotation mode
Data Type Character string type (String)
Range SSTop: Start/Stop
CSPan: Center/Span
Preset Value SSTop
Query Response
{SST|CSP}<newline><^END>
Examples
Dim Var as String
Var= "SSTop"
Ana.WriteString ":SERV:CHAN1:DISP:ANN:XAX:MODE:BIAS " & Var, True
Ana.WriteString ":SERV:CHAN1:DISP:ANN:XAX:MODE:BIAS?", True
Var=Ana.ReadString
Equivalent Softkey
No equivalent key is available on the front panel.
COM Command Syntax (Internal Control Only)
SCPI.SERVICE.CHANNEL(Ch).DISPLAY.ANNOTATION.XAXIS.MODE.BIAS
:SERV:CHAN<Ch>:DISP:ANN:XAX:MODE:FREQ
