Maintenance Fuses
10A
A/Con 3elay, Sub junction block (Cooling Fan 2 3elay),
3CV Control Solenoid Valve, Variable Oil Pump Valve
1A Fuel Pump 3elay
10A Head Lamp 3ight Handle Side
10A Head Lamp Left Handle Side
10A [8ith Mild HEV] BSA Cooling Fan
10A [8ith Mild HEV] BSA Control Module
10A [8ith Mild HEV] Hybrid Starter & Generator Motor
1A ECM (Engine Control Module)
1A ECM (Engine Control Module)
20A Ignition Coil #1, #2, #3
10A Back-Up Lamp Switch
1A ECM (Engine Control Module)
40A ABS/ESC (Electronic Stability Control) Control Module
40A ABS/ESC (Electronic Stability Control) Control Module
40A A/C Blower 3elay
40A Instrument Panel Junction Block (3ear Defogger 3elay)
40A
Instrument Panel Junction Block (Fuse - STOP LAMP,
D3L 2, D3L 1, 3EA3 FOG, F3ONT FOG, MODULE 6,
AUDIO, 3OOM LAMP)
0A
Instrument Panel Junction Block (Fuse - SAFETY 8IN
-
DO8, P/8INDO8 3H, S/HEATE3, P/8INDO8 LH, FOLD
MI33O3, B3AKE S8ITCH, SUN3OOF, IMMOBILISE3,
SMA3T KEY, Power 8indow 3elay)
40A Ignition Switch, PDM 3elay Box (IG 2 3elay), Start 3elay
60A Sub junction block (Cooling Fan 2 3elay)
40A TCM (Transmission Control Module)
40A [8ith Clutch By 8ire] Electronic Clutch Module
40A TCM (Transmission Control Module)
SZmbol Fuse rating Circuit Protected
