Fuses
40A
Instrument Panel Junction Block (Fuse - DOO3 LOCK,
TU3N LAMP, Tail Lamp 3elay)[8ith Mild HEV] Main
3elay, Horn 3elay
40A Ignition Switch, PDM 3elay Box (IG1 3elay, ACC 3elay)
40A Instrument Panel Junction Block (Power Outlet 3elay)
10A Air Conditioner 3elay
20A TCM (Transmission Control Module)
20A Head Lamp LO 3elay
20A Head Lamp HI 3elay
20A Fuel Pump 3elay
1A Burglar Alarm Horn 3elay, Horn 3elay
1A [8ith Clutch By 8ire] Electronic Clutch Module
10A [8ith ISG] Battery Sensor
30A ENG E, ENG E8, Main 3elay
40A CVVD (Continuously Variable Valve Duration) Actuator
40A [Dual Clutch Transmission] Smart Gear Actuator
SZmbol Fuse rating Circuit Protected
