Fuses
Engine room compartment fuse panel (Smartstream G.)
SZmbol Fuse rating Circuit Protected
80A MDPS (Motor Driven Power Steering) Unit
12A / 10A Fuse - ABS 1, ABS 2, BLO8E3, 3EA3 DEFOG
10A
8iper LO 3elay, Front 8iper Motor, Multifunction
Switch
1A ECM (Engine Control Module)
1A
Purge Control Solenoid Valve, Oil Control Valve #1/#2,
Oxygen Sensor (Up/Down)
10A
Cooling Fan 1 3elay, Air Conditioner 3elay, Front 8heel
Sensor 3ight Handle Side, Sub junction block (Cooling
Fan 2 3elay)
1A Fuel Pump 3elay, Injector #1, #2, #3, #4
10A Head Lamp 3ight Handle Side
10A Head Lamp Left Handle Side
1A ECM (Engine Control Module)
1A ECM (Engine Control Module)
20A Ignition Coil #1, #2, #3, #4
10A
[Manual Transmission] Back-Up Lamp Switch
1A ECM (Engine Control Module)
40A
ABS(Anti-lock Brake System)/ ESC (Electronic Stability
Control) Control Module
40A ABS/ESC (Electronic Stability Control) Control Module
40A Air Conditioner Blower 3elay
40A Instrument Panel Junction Block (3ear Defogger 3elay)
40A
Instrument Panel Junction Block (Fuse - STOP LAMP,
D3L 2, D3L 1, 3EA3 FOG, F3ONT FOG, MODULE 6,
AUDIO, 3OOM LAMP)
