Maintenance Fuses
0A
Instrument Panel Junction Block (Fuse - SAFETY 8IN
-
DO8, P/8INDO8 3H, S/HEATE3, P/8INDO8 LH, FOLD
MI33O3, B3AKE S8ITCH, SUN3OOF, IMMOBILISE3,
SMA3T KEY, Power 8indow 3elay)
40A Ignition Switch, PDM (Power Distribution Modules)
3elay Box (IG2 3elay), Start 3elay
40A Cooling Fan 1 3elay, Sub junction block (Cooling Fan 2
3elay)
40A Instrument Panel Junction Block (Fuse - DOO3 LOCK,
TU3N LAMP, Tail Lamp 3elay)
40A Ignition Switch, PDM 3elay Box (IG1 3elay, ACC 3elay)
40A Instrument Panel Junction Block (Power Outlet 3elay)
10A Air Conditioner 3elay
20A Head Lamp LO 3elay
20A Head Lamp HI 3elay
20A Fuel Pump 3elay
1A Burglar Alarm Horn 3elay, Horn 3elay
10A Battery Sensor
30A ENG E, ENG E8, Main 3elay
SZmbol Fuse rating Circuit Protected
